Z-6000 series is a variable area flowmeter instrument, the floating piston has a tapered amount of body, and the body form a conical mouth. Fluid through the meter at both ends to form a sharp edge orifice differential pressure, the float to compress the spring direction. Displacement of the float and flow rate (flow velocity) accurately proportional Flowmeter can be used in any position, even upside down. Float corking observed red indicator ring, it can indicate the measured flow rate. The flowmeter can be installed in any position without affecting the accuracy, which can be installed in horizontal or vertical piping, flow meters used to monitor a variety of liquids and gases.
Temperature: PC: 0 ~ 60 º C
PSU: 0 ~ 100 º C
Accuracy: ± 6%
upper and lower limit alarm switch is optional.
Working pressure: ≤ 1MPa

Model	Measure		Thread
	Measure
	GPM	LPM
Z-6501	3~25	12~90	NPT 1½" NPT 2"
Z-6502	5~50	20~200
Z-6503	8~80	30~280
Z-6504	10~100	40~280
