Yuyao Zhenxing Flowmeter Instrument Factory

The wetted part is 304SS material. The flowmeter is used in chemical analysis apparatus, testing
equipment and scientific development department, the flowmeter has small size and nice shape
also it can be installed on equipment’s control plate.

Temperature Limit: 60℃
Accuracy: ±5%
Working pressure limited: 0.6MPa

Model	DN	Water (ml/min)	Air(NmL/min)	Thread (Female)	Weight (kg)
K-3011	DN3	2.5-25	3-30	1/8˝ NPT*	0.6(304) 0.4(AL)
K-3011	DN3	2.5-25	6-60	1/4˝ NPT
K-3012	DN4	4-40	8-80	1/4˝ NPT 1/4˝ G
			25-250
			100-100
K-3013	DN6	8-80	0.18-1.8 NL/min
		20-200	0.4-4 NL/min
		35-350	0.8-8 NL/min
		40-400	1.5-15 NL/min
		70-700	1.8-18 NL/min
		0.1-1 L/min	3-30 NL/min
