Yuyao Zhenxing Flowmeter Instrument Factory

The wetted part is 304SS material. The flowmeter is used in chemical analysis apparatus, testing
equipment and scientific development department, the flowmeter has small size and nice shape
also it can be installed on equipment’s control plate.

Temperature Limit: 60℃
Accuracy: ±5%
Working pressure limited: 0.6MPa

Model	Water (mL/min)	Air (NL/min)	Thread (Female)	Weight (kg)
K-2011	20-200	0.3-3	1/8˝NPT *	0.5
K-2012	30-300	0.5-5	1/4˝ NPT
K-2013	50-500	1-10	1/4˝NPT 1/4˝G
K-2014	0.1-1 L/min	2-20
K-2015	0.15-1.5 L/min	3-30
K-2016	0.2-2 L/min	5-50
