Diameter: DN10mm-DN150
Electrode: 316L,Hb,Hc,Ti,Tan,Pt
Liner: PTFE,PFA,F46
Medium: conductivity liquids
Medium conductivity : ≥5μ s/cm
Accuracy: ±0.25%RS,±0.5%RS,±1.0%RS
Velocity of flow：0.1m/s-10m/s
Working temperature:-25°C~150°C (base on material)
Working pressure:0.6MPa-1.6MPa(base on diameter)
Output:4-20mA/ frequency/pulse output signal
Power supply:220VAC/24VDC,battery
Installation type: Compact, remote
Communication:RS485 or HART protocol is optional
|
D N(mm)
|
L
|
D
|
H
|
|
25
|
90
|
72
|
112
|
|
32
|
90
|
82
|
122
|
|
40
|
90
|
92
|
132
|
|
50
|
125
|
108
|
148
|
|
65
|
125
|
128
|
168
|
|
80
|
130
|
142
|
182
|
|
100
|
160
|
162
|
202
|
|
125
|
170
|
192
|
232
|
|
150
|
185
|
219
|
259
|
DN
mm
|
Min flow
m3/h
|
Flow Range Selection（m3/h）
|
|
10
|
0.08
|
0.16, 0.2, 0.25, 0.3, 0.4,0.5,0.6,0.8,1.0,1.2,1.6,2.0,2.5
|
|
15
|
0.2
|
0.4,0.5,0.6,0.8,1.0,1.2,1.6,2.0,2.5,3.0,4.0,5.0,6.0
|
|
20
|
0.3
|
0.6,0.8,1.0,1.2,1.6,2.0,2.5,3.0,4.0,5.0,6.0,8.0,10.0
|
|
25
|
0.5
|
1.0,1.2,1.6,2.0,2.5,3.0,4.0,5.0,6.0,8.0,10.0,12.0,14.0,16.0
|
|
32
|
0.8
|
1.6,2.0,2.5,3.0,4.0,5.0,6.0,8.0,10.0,12.16,20,25
|
|
40
|
1.2
|
2.5, 3.0, 4.0, 5.0, 6.0, 8.0,10.0,12,16,20,25,30,40
|
|
50
|
2
|
4.0, 5.0, 6.0, 8.0, 10, 12,16,20,25,30,40,50,60,70
|
|
65
|
3.5
|
6.0,8.0,10,12,16,20,25,30,40,50,60,80,100,120
|
|
80
|
5
|
10,12,16,20,25,30,40,50,60,80,100,120,160
|
|
100
|
8
|
16,20,25,30,40,50,60,80,100,120,160,200,250
|
|
125
|
12
|
25,30,40,50,60,80,100,120,160,200,250,300,400
|
|
150
|
18
|
40,50,60,80,100,120,160,200,250,300,400,500,600
|
|
200
|
30
|
60,80,100,120,160,200,250,300,400,500,600,800,1000
|
|
250
|
50
|
100, 120, 160, 200, 250, 300, 400, 500, 600, 800, 1000, 1200, 1600
|
|
300
|
70
|
160, 200, 250, 300, 400, 500, 600, 800, 1000, 1200, 1600, 2000, 2500
|
|
350
|
100
|
200, 250, 300, 400, 500, 600, 800, 1000, 1200, 1600, 2000, 2500, 3000
|
|
400
|
120
|
250, 300, 400, 500, 600, 800, 1000, 1200, 1600, 2000, 2500, 3000, 4000
|
|
450
|
160
|
300, 400, 500, 600, 800, 1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000
|
|
500
|
200
|
400, 500, 600, 800, 1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000, 6000
|
|
600
|
300
|
600, 800, 1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000, 6000, 10000
|
|
700
|
400
|
800, 1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000, 6000, 10000, 12000
|
|
800
|
500
|
1000, 1200, 1600, 2000, 2500, 3000, 4000, 5000, 6000, 10000, 12000, 16000
|
|
900
|
650
|
1200, 1600, 2000, 2500, 3000, 4000, 5000, 6000, 8000, 10000, 12000, 16000, 18000
|
|
1000
|
800
|
1600, 2000, 2500, 3000, 4000, 5000, 6000, 10000, 12000, 16000, 20000
|
|
1200
|
1200
|
2500, 3000, 4000, 5000, 6000, 8000, 10000, 12000, 16000, 20000, 25000, 30000
|
|
1400
|
1500
|
3000, 4000, 5000, 6000, 8000, 10000, 12000, 16000, 20000, 25000, 30000, 40000
|
|
1600
|
2000
|
4000, 5000, 6000, 8000, 10000,1 2000, 16000, 20000,2 5000, 30000, 40000,50000, 60000
|
|
1800
|
2500
|
5000, 6000, 8000, 10000, 12000, 16000, 20000, 25000, 30000, 40000, 50000, 60000
|
|
2000
|
3000
|
6000, 8000, 10000, 12000, 16000, 20000, 25000, 30000, 40000, 50000, 60000, 80000, 100000
|
